Atlas Thread Gage, Inc.
Calibration Price List
PURCHASE ORDER INSTRUCTION
*NOTE: When sending in gages for recertification please send an itemized list of all your gages, and keep a copy
for your records. Also, indicate if you would like us to replace any out of spec. gages. When sending in ring gages for calibration it is best, but not required to send in your set plugs so we can set your ring gages to your set plug gages.
All orders are handled on a first come first serve basis.
Turn-around time is approximately 2-3 weeks depending on our workload and the size of your order. In order to receive the best turn-around time we found it best to send gages in smaller batches of 25 gages or less.
GAGE DESCRIPTION USED GAGES  NEW GAGES
THREAD PLUG GAGE MEMBERS UP TO 2" DIA. 10.50 8.50
THREAD PLUG GAGE MEMBERS OVER 2" DIA. 15.00 8.50
STANDARD THREAD RING GAGES UP TO 1 1/2" DIA. 38.00 8.50
THREAD RING GAGES OVER 1 1/2" DIA. 48.00 8.50
SPECIAL SIZE THREAD RING GAGES (IF MASTER IS AVALIABLE) 48.00 8.50
THREAD RING GAGES SOLID TYPE MASTER 65.00 8.50
TAPERPIPE THREAD PLUG GAGE MEMBERS UP TO 2" DIA. 35.00 8.50
TAPERPIPE THREAD PLUG GAGE MEMBERS OVER 2" DIA. 65.00 8.50
TAPERPIPE RING GAGES UP TO 1" DIA. 45.00 8.50
TAPERPIPE RING GAGES 1 1/4" - 2" DIA. 60.00 8.50
TAPERPIPE TRUNCATION PLUG GAGES MEMBERS UP TO 2" DIA. 48.00 8.50
TAPERPIPE TRUNCATION RING GAGES UP TO 2" DIA. 65.00 8.50
SPECIAL THREAD GAGES: OBTUSE, ACME, BSP, BUTRESS,
WHITWORTH, DOUBLE LEAD, SPECIAL ANGLE, ETC.
Upon Request 8.50
STEPS ON THREAD PLUG GAGES EXTRA CHARGE PER STEP 8.00 5.00
PH.# 248-477-3230
Notice
Per ISO/IEC 17025:2005 requiremements...
Gages sent in for recertification must be identified by a unique
Identification No.
If gages are sent in without identifiacation numbers
Atlas will contact you to have Identification No.'s
assigned to your gages.
Addition charge for marking
may apply.
